DC Supplies :           +5V/500mA

Clock Generators     :           Fixed : 0.1Hz, 1Hz (simultaneous  5Vindependent outputs)

Variable :      One low frequency  variable clock  generator

Manual Pulser          :           One independent buffered bounceless manual pulser (useful to freezing the action of each stage of the counter after every clock pulse).

Logic Level Inputs    :           Eight independent buffered logic level inputs to select high/low TTL levels, each with a LED to indicate high/low staturs and termination.

Logic Level Indicators         :           Eight independent buffered logic level indicators for High/low status indication of digital outputs.

 Power ON      :           Power ON switch with indicator for mains on indication and fuse for protection.

 Patch Cords  :           Set of 20 assorted coloured multi-stand wires with 2mm stackable plug termination at both ends.

 Power Requirement :           230 ±10%V AC, 50Hz, single phase.

  Accessories :           Instruction Manual.

EXPERIMENTS CAN BE PERFORM

            Study of basic gates and verification of their truth tables (NOT, OR, AND, NOR, NAND, EX-OR, EX-NOR).

            Study and verifications of the laws of Boolean Algebra and De-morgan’s theorem.

            Study of important TTL terminologies, verification of important TTL circuit parameters.

            Construction and verifications of various types of flip-flops using gates & IC’s (RS, JK, D, T, M/SJK).

            Construction and verification of various types of combinational circuits such as Half Adder, Full Adder, Half Subtractor, Full Subtractor, Even/Odd Parity                   Checker, Multiplexer, Demultiplexer, Binary to Gray & Gray to Binary converters.

            Construction and verification of various types of Up/Down, Synchronous Asynchronous, Ripple, Reverse, Ring, Binary, BCD & Decade Counters.

            Construction and varification of 4 bit universal shift register (SR/SL operation).

            Study of 7-segment display and decoder/driver.
